Drone Delivery, Transportation & Shipping Applications

Drone Food Shipping

Pharmaceutical Shipping

Shore-to-Ship Drone Transport

Air Taxis with Coupled-Poles

Small Package Drone Delivery

Regional Aerial Autonomous Delivery

Small Package Drone Shipping

Amazon Air Prime

Warehouse Direct to Consumers

UPS Last Mile

Truck Launch Drone Delivery

FedEx Wing

Zipline Drone Delivery

DHL Drone

International to Business

Walmart Aerial

Bag Delivery

Airogistic Conceptual

Delivery Warehouse

DroneDome

Coupled-Pole

Drone Stand

Pharmaceutical & Medical Delivery Drone

● Warehouse drone shipping stations

● Networked cluster of drone stations

● Pharmaceutical & drug delivery

● Most pharma products weight <2 lbs

● Pharmaceuticals expire on shelves

● Pharmaceuticals retailers reduce cost 25-50%

● Just-in-Time delivery from centralized warehouse

● Air delivery to local pharmacies, hospitals, doctors

Fast Food and Grocery Drone Delivery

Brand Chains Testing Drone

Delivery

Uber

Eats

Domino

Pizza

Hut

About Food and Grocery Drone Delivery Market

• Food Delivery Project to be a Major Market for Drone Delivery

• Small Order Fast Food is Being Tested in Dallas, Texas

• Beyond-Line-of Sight Regulations Block US Market Adoption

• Early Focus is on the Drone & Food Payload Packaging

• Backend Automation for Oven-to-Drone and Cart-to-Drone is TBD

• Coupled-Pole Launch/Land/Test/Charge Stations offer Value

Coupled-Pole Drone Stand Key Features

• Rapid turnaround charging

• Secure dynamic mission upload

• Secure drone pole-locking

• Preflight payload mass balancing & mass test

• Mission endurance verification

• Preflight launch diagnostics

• Machine learning predictive maintenance

Papa Johns

Wing-DoorDash Wendy’s

Ship-to-Shore & Shore-to-Ship Drone Aerial Transport

Application Attributes

• Market Vertical: Ship-to-Shore

• Application Type: Transportation

• Application Objective: Delivery

• Market Type: Commercial

• Beyond Visual Line of Sight

• Station Mount: Mobile, Stationary

Drone Requirements

• Multiple Drone Support: Yes

• Automate Landing Required: Yes

• Drone Type: Open

• Drone Size: Mid, Large

• Drone Endurance: Mid, High

Mission Parameters

• Mission Execution: Command, Schedule

• Mission Waypoints: Predefined

• Mission Altitude: Low, Mid, High

• Mission Airspace Contention: Yes

• Mission Temperature: All

• Mission Weather: Fair

Safety and Compliance

• Optional Pilot: Yes

• Drone ID Required: Yes

• Emergency Land Zone: Yes

• Parachute Required: Yes

Station Capabilities

• Multi-Launch: Yes

• Coordinated Drone Handoff: Yes

• Preflight Test: Yes

• Payload Balancing: Yes

• Predictive Maintenance: Yes

• Direct Service and Support: Yes

Regional Aerial Autonomous Transport

Reduce highway trucking with drone aircraft

• Hybrid Electric, Fossil Fuel and Hydrogen Propulsion

• Freight Carriers scales from 100 lbs. up to a few tons

• Mixed Vertical Lift and Forward Propeller

• Some designs employ Tilt Wing or Rotor Designs

• US States region air authority supported

• FAA test & aircraft qualification UAS development

• Region air corridors being established

• Low altitude radars and Vertiport designs

• Air Force supported R&D via AFRL for military logistics

US State Regional

Delivery Drone

Development Centers

New York State

• 50-mile corridor stretching

• Syracuse to Rome

• BYLOS testing

• GENIUSNY

• NUAIR

• Griffiss Air Force Base

• AFRL

Texas

• Dallas-Fort Worth

• AllianceTexas

• Mobility Innovation Zone (MIZ)

• Perot Field

• Fort Worth Alliance Airport

• Bell, Amazon, Wing & Zipline

• BVLOS testing

Michigan

• Michigan & Ontario

• Air Mobility Corridor

• BVLOS Testing

• Alpena to Camp Grayling by

2025

• Uncrewed Triple Challenge

• Autonomous Competitions

Air Taxis Using Coupled Drone Stations

Challenge of Urban Mobility in the Next Century

• Air taxis are necessary for future reductions in urban Traffic

• 3D dimension aerial and ground transport will be required

• Commuters seeing air taxis flying over traffic will invest

• Low altitude 3D airspace can not scale to allow all to own

• Commuter air taxis with taxis pooling will be necessary

• Autonomous and pilotless operation will be required for ROI

• Safety is critically important for air taxis market adoption

• With no pilots & minimal ground crew how will Air Taxis work

• Station which charge/fuel

• Airogistic Patented Air Taxis Operations and Safet

Coupled Pole Air Taxis

Launch/Land/Test/Recharge Station

What is Air Taxi Station? where and how should it be built? (aviationfile.com)
