Commercial Drone Inspection Applications

Aerial Surveying

Roof Inspection

Service Truck

Coupled-Poled

Drone Station

Features:

• Auto Charging

• Mission Loading

• Preflight Testing

• Preventive Diags

• Data Upload

• Secure Transport

Pipe & Below Ground

Penetrating Radar

Obstacle Detection

Pipeline Inspection & Security

Construction Inspection & Security

Mobile Service Truck Drones for Roof Inspection

• Market Vertical: Roofing Inspection

• Application Type: Monitoring

• Application Objective: Observation

• Market Type: Commercial

• Market Regulations: Line of Sight (LOS)

• Station Mount Type: Mobile

Drone and Stand Requirements

• Option for Tethering Support: Yes

• Drone Type: Shrouded

• Drone Size: Small

• Drone Endurance: Low, Mid

• Mission Execution: Command

• Mission Waypoints: Dynamic

• Mission Altitude: Low, Mid

• Mission Temperature: Mid

• Mission Weather: Fair

• Optional Pilot: Yes

• Drone ID Required: Yes

• Emergency Land Zone: Yes

• Parachute Required: Yes

• Indoor/Outdoor: Outdoor

• Day/Night : Day Time

Mission Payload Requirements

• Payload Mass: Light

• High Def Camera: Yes

• Thermal Camera: Yes

• LIDAR: Yes

• Still Image Recording: Yes

• Live Camera Video Feed: Yes

• Camera Optical Zoom: Yes

• Precise Gimbal Control: Yes

• Gimbal High Stabilization: Yes

• High Lumina Light: Yes

• Video Recording: Yes

• Live Image/Video Analysis: Yes

• Object Avoidance Required: Yes

• Image/Video Obscuring: Yes

• Preflight Test: Yes

• Predictive Maintenance : Yes

• Low Cost 3D Printed Drone: No

• Direct Service and Support: Yes

Service

Pickup

Truck

Mount

Launch

Drone Pipeline Inspection and Security

Drone Requirements

• High Stability: Low Altitude over 3D Terrain

• Guidance: RTK GPS Guidance & Visual Correction

• Flight Conditions: Wind Rain, Dust, Sand, Snow

• Payload Capacity : Small or Mid for Leak Detection

• Enduring: Long Flight Times

• Agility: Navigate around pipeline infrastructure

• Safety: High Safety, Shrouded, Foam

Drone Payload Requirements and Options

• High Resolution Camera: Waypoint Optical Zoom

• Thermal Camera: Thermal Leak & Corrosion Detect

• Multi-Spectral Camera: Vegetation and Emissions

• Gas Detectors: Leak Concentration Detection

Drone Station Requirements and Options

• Installation: Mobile Truck, UGV or Fixed Station

• Remote Power Generation: Solar Wind

• Remote Communications: Starlink: Satellite or 4G

• Flight Operations: Scheduled or On Demand

• Preflight Testing: High reliability and Safety

• Maintenance: Scheduled and AIML Detected Repair

Construction Inspection, Progress Tracking & Security

• Construction Progress Tracking

• Site Inventory Management

• Site Security

• Worker Safety Monitoring

• Vehicle or Trailer Station Launch/Land

• Off-hour and Nighttime Monitoring

• Autonomous Operations

• Safe Foam Shrouded Drone Design

• Preflight and Post Test

• Remote Power

• Satellite Data Load

• Low Cost Drone

High Rise Building Inspection & Windows Maintenance

Drone Requirements

• High Stability: Operates Very Close to Buildings

• Guidance: Visual, Lidar or Ultrasonic Guidance

• Flight Conditions: Fair Weather

• Payload Capacity : Heavy for Tank or Hose

• Tethered Operation : For Hose Liquid Supply

• High Endurance : For Tak Operations

• Safety: High Safety, Shrouded, Foam …

Drone Payload Requirements and Options

• Tethered Hose

• Tanks for Sprayer

• Changeable Replaceable Nozzle

Drone Station Requirements and Options

• Installation: Mobile Truck, UGV

• Communications: Secure Wi-Fi

• Flight Operations: Push Button On Demand

• Preflight Testing: High Reliability and Safety

• Maintenance: AIML Detected and Repair

Warehouse, Store or Workshop Inventory Drone

Indoor Warehouse & Retail

Inventory Drone Features

• Inventory Security Drone Requirements

• Active Target Waypoint Navigation

• Visual and Inertial Odometry

• Object Avoidance

• AI Assist Inventory Counting

• Safe Shrouded Prop Design

• Light Weight Foam Multi-drone Swarm Coverage

• High Safety and Reliability

• Autonomous Drone Launch/Land

• Fast Coupled Battery Charge

• Coupled-Pole Preflight & post Land Diagnostics

• Predictive Maintenance and Replacement

• Low Cost

• High Reliability

• Simple Setup, Scheduling, Path Plan & Operation

Aerial Drone Surveying

Rural & Large Land Tract Surveying

• Aerial Surveying by Drone Accuracies >=

Traditional Surveying Methods

• Augment Crews with Truck Mount Launch

• Mobile Coupled-Pole Stations Enhances:

§ Drone Reliability

§ Operational Safety

§ Measurement Repeatability

• Stations Combined with BYLOS

Operations:

§ Increase Worker Efficiency

§ Reduce Survey Time

§ Reduce Survey Costs

• Enhanced Survey Stations Validate:

§ Drone and Ground RTK GPS Rovers

§ Check and Field Calibrate Camera

§ Check Surveying LIDAR

§ Charge on the road

§ Automate Preflight Tests

§ Automate Data Upload
